Shandong Muke Sensor's core products cover a full range of industrial safety sensing equipment, including safety light curtains, bending machine laser protection devices, and safety carpets. They are widely used in automotive manufacturing, white goods, textiles, packaging, new energy, stamping and forging, and non-standard automation fields, providing customized safety sensing solutions for customers worldwide.
Product Industry Advantages 1. Box Bending Functionality：Capable of standard workpiece bending (e.g., cable trays, U-shaped profiles) and complex box-shaped part forming (e.g., distribution boxes, door panels, switching power supplies, electrical cabinets, curtain walls). Operates in three distinct modes: Normal Mode, Box Bending Mode, and Shielding Mode. 2. Upper/Lower Die Mounting Compatibility：Mounts on either the upper die or lower die. Lower die installation optimizes tool-change efficiency, enhancing customer satisfaction. For fixed lower die configurations, single calibration ensures position stability with minimal post-installation adjustment. 3. Five-Point Protection System：Features a five-point protection zone, offering expanded coverage compared to single-point or three-point systems. 4. Slow Descent Delayed Protection：Integrates slow descent delayed protection: After entering slow descent phase, the light curtain maintains safeguarding for 1 second (factory-configurable duration, adjustable ±0.5s). 5. Fault Indicator Flashing Alert：Adds fault indicator flashing: Triggers intermittent illumination during light obstruction or beam misalignment, alerting operators to safeguarding anomalies. |
Detailed Product Parameters ◉ Detection Light Source: Class 1 Laser Product (Wavelength: 635 nm) ◉ Protective Distance: 0–20 m ◉ Beam Divergence Angle: 1.5 mrad ◉ Operating Temperature Range: –10°C to 50°C (Condensation-Free) ◉ Storage Temperature Range: –30°C to 70°C ◉ Ambient Humidity: 35% to 85% RH ◉ Ingress Protection Rating:- Sensor: IP65；- Controller: IP20；- Operator Interface: IP54 ◉ Current Consumption: ≤ 450 mA ◉ Response Time: ≤ 12 ms ◉ Resistance to Optical Interference: Compliant with IEC 61496-1:2020 (Type 4) ◉ Vibration Resistance: Compliant with IEC 61496-1:2020 (Type 4) ◉ Shock Resistance: Compliant with IEC 61496-1:2020 (Type 4) |
Our Advantages
Shandong Moncee is a modern integrated manufacturer specializing in R&D, design, production, sales, and service, with self-owned production facilities covering 20,000 m². Our MILS-F31C LiDAR delivers tailored, cost-effective solutions for all application requirements. It provides compact data output for environmental monitoring and object detection, enables enhanced flexibility in industrial environments and building automation systems, and serves as a core sensor for mobile platforms—including autonomous mobile robots (AMRs), service robots, and ground transportation vehicles. Specialized variants are engineered for critical safety applications, specifically designed for personnel protection and secure mobile operations in industrial settings. As the industry’s first programmable 2D LiDAR, it achieves highly customizable performance advantages through advanced configuration.
|
|
|
High Safety Level Effectively monitors any opaque object entering the light curtain area that exceeds the detection accuracy. Suitable for on-site safety protection and complies with Safety Level 4 requirements. | Compatible Controller Can be used in conjunction with SBC, SPC, and SR series controllers to enable the automatic shutdown function during hazardous conditions. | Integrated Signal If a risk assessment permits operation without an external controller, or when level signals are required, the safety light curtain can integrate this function directly into the sensor to output signals natively. |
Express Shipping on Order (Packing List)
